RE-6000 Rotary Evaporator

Introduction:

1.RE-6000 6L Rotary Evaporator

2.Production-oriented large-capacity rotating steam rotary evaporator flask. Increase the evaporation area, placed in a water bath under vacuum, side spin, while heating, so proliferating of high-performance solution evaporated.

3.It is widely used in the size of the sample concentration, drying, extraction, recycling and so on.

4.It is the ideal equipment for small mass production of chemical industry, medicine, food, environmental protection, institutions of higher learning and scientific research laboratories and industries and mining units.

H23d6357f12f84a7f94020a77161e4db60 (1) (1).jpg

Features:

1.Host parts: the introduction of foreign advanced transmission system, reasonable structure, durable and practical.

2.Control, temperature parts: the introduction of foreign advanced frequency control system, temperature control system to ensure accurate performance of the instrument.

3.Water bath: one made of imported stainless steel plate stamping, automatic vertical lift.

4.Sealing parts: the PTFE material selected foreign countries, through special processing technology to enhance sealing, corrosion resistance and wear resistance.

5.The main structure: high quality aluminum alloy and stainless steel, more complete and improve the equipment of a reasonable performance.

6.Electric Automatic Lifting System has the function of implantable guide bush sliding speed smooth no impact .

7.Water bath pot electric lift, up the largest decline in range of 0~190mm.

8.The Heating BathEquiped With transparent protection cover with  heat preservation ,energy conservation, explosion proof,spray proof, antifouling .


Specifications:

1.Rotary Bottle capacity : 6L (6 liters)

2.Collection bottle capacity: 3L (3liters)

3.Master speed:   10-150 rpm with digital display

4.Lifting : Electric Automatical Lifting Water Bath Range From 0~180mm

5.Condenser :  Vertical type, double-reflux integration standard joint condense pipe.Equipped with standard joint receiving flask.

6.Water Bath : One Time forming of stainless steel water bath Pot

7.Temperature Controller: digital display, setting temperature precisely. RT ~99°C

8.Supply Voltage: ~ 220v/50Hz

9.Heating power: 1.5 Kw

10.Lifting : Electric Automatical Lifting Water Bath (0~180mm)

11.Instruments Dimension : L * W * H 53 * 38 * 93 cm
