XPZ-830BI Stereo Zoom Microscope

Brand:NANBEI

Model:XPZ-830BI

Application:

CONTACT NOW Chat Now

product details

XPZ-830BI Stereo Zoom Microscope

XPZ830 is a big zoom stereomicroscope with high performance, the zoom ratio is 1:8:3. The series adopt building block structure and can easily and quickly mount the functional components, such as photographic system, CCD, Digital camera for the convenience of taking pictures and coaxial illuminating. It adopts the parallel optical paths. And the common bojective with non-coaxial imaging techniques, whick improve definition of the visual field edge, strengthen three-dimension effect and offer a clear effect on obdervation object with bright background. The series microscopes have a character of big working table , comfortable usage. easy operationg and reliable performance.. It can be used extensively for mediacal and hygienic work, agriculture and electron and precision machinery.

It is particularly suitable for the test of LC maked film, LCD printing paste, LED production, PCB board, pressing and plating and electron compeonents.

Standard configurations

zoom ratio	1:8.3
Objective zoom range	0.6X-5X
Eyepice	SWF10X/22mm
Working distance	95mm
Interpupillary distance adjustment range	48mm-75mm
Binocular head	inclination of 45。
Diopter adjustment	±5 diopter
Optical Body Rotation。	360
Voltage input	110V/60HZ or 220V/50HZ
Top halogen lamp	6V15W adjustable brightness
Bottom fluorescent lamp	5W

Technical data

Project	Auxiliary Objective	Eyepiece								Working distance(mm)
		SXF10X		WFl5X		WF20X		WF25X
		Magnifi-cation	Visual field	Magnifi-cation	Visual field	Magnifi-cation	Visual field	Magnifi-cation n	Visual field
Data	0.3X
	0.5X	3X-25X	73-8.8	4.5X-37.5X	53.3-6.4	6X-50X	43.3-5.2	7.5X-62.5X	40-4.8	200
	1X	6X-50X	36.7-4.4	9X-75X	26.7-3.2	12X-100X	21.6-2.6	15X-125X	20-2.4	95
	1.5X	9X-75X	24.4-2.9	13.5X-112.5X	17.7-2.1	18X-150X	14.4-1.7	22.5X-187.5X	13.3-1.6	55
	2X	12X-100X	18.4-2.2	18X-150X	13.3-1.6	24X-200X	10.8-1.3	30X-250X	10-1.2	35
