Stereo Microscopes XTB-01


The XTB Series stereo microscope line is a resilient, robust, high performance optical system for the most demanding environment. With a zoom ration of 1:4 and 97MM working distance, it is ideally suited for quality control, “back end manufacturing”, medical device inspection, and many other medical and electronic manufacturing applications. These models are supplied with 10X super wide-field high point eyepieces as standard. The mechanical focusing and zoom systems are simple to use, and designed to perform flawlessly for many years. GLO offers an extensive variety of stand types, eyepieces, auxiliary objectives, imaging adapters, light sources and dissection kits to complement the basic microscope system. This model line is well suited for both professional manufacturing and educational locales.

Standard configurations

Zoom ratio 1:4
Objective zoom range 1X-4X
Eyepice,Big Eyepiece 10X eyepiece, 20Xeyepiece, 2X big eyepiece
Working distance 95mm
Interpupillary distance adjustment range 55mm-75mm
Binocular head inclination of 45。
Diopter adjustment ±5 diopter
Optical body rotation 360。
Technical data
Project
Auxiliary Objective
Eyepiece
Working distance(mm)
WF10X
WFl5X
WF20X
WF25X
Magnifi-cation
Visual field
Magnifi-cation
Visual field
Magnifi-cation
Visual field
Magnifi-cation
Visual field
Data
0.5X
5X-20X
40-10
7.5X-30X
32-8
10X-40X
26-6.6
12.5X-50X
24-6
160
0.75X
7.5X-30X
26.7-6.7
11.3X-45X
21.3-5.3
15X-60X
17.3-4.4
18.8X-75X
16-4
120
1X
10X-40X
20-5
15X-60X
16-4
20X-80X
13-3.3
25X-100X
12-3
97
1.5X
15X-60X
13.3-3.3
22.5X-90X
10.7-2.7
30X-120X
8.7-2.2
37.5X-150X
8-2
45
2X
20X-80X
10-2.5
30X-120X
8-2
40X-160X
6.5-1.6
50X-200X
6-1.5
30
