MP-2B Grinding & Polishing Machine

Model MP-2B Metallography specimen grinding & polishing machine is equipped with double disks and features stepless speed changing grinding and polishing. It can finish the whole process of rough grinding, fine grinding, rough polishing and finishing polishing for specimen preparing. By adjusting the transducer, it can realize the rotating speed of grinding and polishing disk adjustable from 50 to 1000 rpm. This bring this machine with much more extensive applying and make it become the necessary metallography specimen preparing instrument for using in  factories, scientific research institutes and laboratories of colleges.

Technical Specifications

1. Digital display of rotating speeds of grinding and polishing disks

2. Power supply: 220V, 50Hz

3. Diameter of grinding disk: Ø230mm, rotating speed 50-1000 rpm

4. Diameter of polishing disk: Ø200mm, rotating speed 50-1000 rpm

5. Diameter of sand paper: Ø200mm

6. Motor: YSS7124, 550W

7. Dimensions: 73 × 66 × 30 cm

8. Net weight: 45 Kg
