I. Summary
The instrument is suitable to determine absolute viscosity of Newtonian Liquids and apparent viscosity of Non-Newtonian Liquids. It can be used to determine the viscosity of petroleum oil, resin, paint, ink, sizing agent, cosmetic, cream, medicine, and asphalt, etc. When you determine different liquids, please select different measurement units as per their different viscosities and different test requirements. The instrument has characteristics of small, light, convenient, easy to be maintained, durable and it can determine the viscosity of liquids quickly and reliably.
II. Main technical specifications
1. Measurement range: 1 mPa·s～1×106 mPa·s
2. Measuring accuracy: ±5% (For Newtonian Liquids)
3. Measuring unit: Unit II and Unit III
4. Rotating speed: 750 RPM, 75 RPM, 7.5 RPM
5. Power supply: AC 220 V±10%, 50 Hz
6. Dimension: 170 mm×140 mm×440 mm
7. Weight: 15 kg
