100KN 300KN 600KN 1000KN 2000KN 3000KN Microcomputer Display Hydraulic Universal Testing Machine

Brand:NANBEI

Model:WEW－100 WEW－300 WEW－600 WEW－1000 WEW－2000 WEW－3000

Application:

CONTACT NOW Chat Now

product details

1. Applications and features:

WEW series of Computer Display Hydraulic Universal Testing Machine adopts the cylinder underneath type main engine, use a load cell to measure force. The machine configured import oil pump unit and oil source, clamping automatically, simple operation and if increase affix it could expand test range. This tester is mainly used for metal, plastic, concrete, cement and other non-metal materials’ tensile, compression, bending and shear test and etc. The computer can get parameter automatically, such as tensile strength, yield strength and elastic modulus E according to GB/T228 "metallic materials tensile test at room temperature method”.

2. Main technical parameters:

Model specifications		WEW－100	WEW－300		WEW－600	WEW－1000	WEW－2000	WEW－3000
Max. Capacity(KN)		100	300		600	1000	2000	3000
structural style		Two column	Two column		Four column	Four column	Four column	Four column
Precision of force		±1% or ±0.5%
Testing level		1, 2, 5, 10 （automatically level change）
Test force range (kN）		2%～100%
Measurement accuracy		±0.5%
Deformation resolution(μm）		2
Testing space	Stretching space(mm)	600		600	600	650	750	800
	Compression space(mm)	550		550	550	580	650	700
	Valid width(mm)	460		460	500	520	650	750
	Oil cylinder stroke(mm)	200		200	250	250	250	250
External dimensions(mm)		720×580×1770 （max.1970）		720×580×1770 （max.1970）	800×620×2050 （max.2300）	860×660×2170 （max.2420）	950×620×3000（max.3300）	1100×750×3100（max.3400）
Bending test fulcrum distance(mm)		30～450		30～450	30～480	40～480	60～500	60～500
Shear test section size		Φ10		Φ10	Φ10	Φ10	Φ20	Φ20
Round specimen clamping diameter(mm)		Φ5～Φ20		Φ10～Φ32	Φ13～Φ40	Φ20～Φ60	Φ20～Φ80	Φ20～Φ100
Flat specimen dimensions(thickness*width))		0～15×75		0～15×75	0～30×80	0～40×110	10～60×120	10～80×120
Power(kw）		2.1		2.1	2.3	2.3	3.5	5
Voltage		220V and 380V (Can configured with national standard voltage)
Weight(kg)		1500		1500	2500	3100	5000	6500

3. Functions

1）Software packages

The computer data processing software is based on WindowsXP operating system platform. It can satisfy different testing materials and complete tensile, compression and bending tests.

Features of the software package:

(1) Measuring the force value, deformation and displacement synchronously.

(2) Test curve real-time display

(3) Can delete arbitrary testing result arbitrarily.

(4) Can zoom and print testing curve. Can select parameter points on the curve (yield point, elastic, etc).

(5) Use VB+SQL language to calculate parameter, it is reliable and convenient.

(6) Can obtain metal materials tensile( pressure) strength, yield strength, δ0.2, disproportional strength, elongation strength etc.

2) Microcomputer system: Use the Lenovo brand microcomputer as host machine to finish the testing setting setup, data acquisition, display and print test results etc(include: main engine, 17 "LCD and large capacity hard disk); equipped with KQL-PowerTest2001 in English and Chinese version which is intelligent test software packages; Can provide standard measurement and judgment of performance parameter for all kinds of material, add up and processing the data; output various requirements of the test report and test format curve.

3) Computed mode: Hand valve operation, and equipped with manual control operation box, contains 6 buttons (rise，fall, upper clamping, bottom clamping, upper loosen, bottom loosen), the operation more convenient, safe and reliable.

4) Safety protection: Equipped with oil cylinder protection system, overload autostop system, overcurrent outostop system and emergency switch protect function.

4．Advantages:

(1) The main machine is using oil cylinder underneath structure. If the testing force greater than 600KN, it should use 6 pillars connect to the upper beam and working table.

(2) Adopt automatically hydraulic to clamp the specimen, not easy sliding.

(3) Adopt spoke structure loading sensor. It has advantage of high precision and stable performance.

(4) The oil pump is imported from Italia, low noise, stable oil and no impact.

(5) Hydraulic sealed with double sealing structure, effectively prevent the leakage of oil and oil leakage.

(6) Configured Clamp mouth protection board, this could effectively prevent the splint of clamp mouth scratched.

5. Disadvantages:

The product adopt hand valve operation, computer processing experimental data, no computer control test function, cannot realize a constant force and no constant loading function.
