SP-5 Video Measuring Apparatus

MODEL SP-5 VIDEO MEASURING APPARATUS

Feature & Use:

* Direct indentation image display on LCD and direct hardness measurement through LCD.

* Double function optional for measuring microscope.

* SP-5 can be mounted onto our Vickers and micro-Vickers hardness testers (200HV-5, 200HVS-5, 310HVS-5, HV-1000A, HV-1000B, HVS-1000A and HVS-1000B etc.)

SP-5 is designed on the basis of traditional measuring microscope. It adds optical measuring components, CCD measuring components, 8" colorful LCD display components to microscope, and it can help to display the indentation image on LCD and make hardness test directly. In this way, the human error caused by long time eye viewing through microscope can be reduced. It is especially the ideal means for multiple persons to measure at the same time. It can be widely applied in constitutes, research dept. and factories.

Specifications：

SP-5 is equipped with digital microscope (with rotary encoder) and combined with 40X objective lens:  Resolution: 0.01um

SP-5 is equipped with manual microscope (without rotary encoder) and combined with 40X objective lens:  Resolution: 0.125um

SP-5 is equipped with manual microscope (without rotary encoder) and combined with 1X objective lens:  Resolution: 5um

Measuring range:  Combined with 40X objective lens: 125 um

                             Combined with 10X objective lens: 500 um

                             Combined with 1X objective lens: 5000 um

Optical system:

Total magnification: 400X (measurement)

             100X (measurement)

             1X (measurement)

CCD system:

Horizontal definition: 570 lines

Display mode: Black and white

Input voltage: DC12V±10%

LCD display system:

Screen size: 8”

 Input voltage: DC12V±10%

Voltage stabilizer input voltage: 220V, 50Hz

Power consumption: ≤20W

Dimensions: φ47×170mm

Weight: 1 kg

Standard accessories

CCD camera

LCD screen

Optical part
