2X-4A 4L/s rotary vane vacuum pump
2X-4A 4L/s rotary vane vacuum pump

2X-4A 4L/s rotary vane vacuum pump

Brand:NANBEI

Model:2X-4A

Application:

product details

This series of pumps are elementary equipment for pumping air from sealed vessels. It can be used alone, also can be used as the forepump, process pump or titanium pump of booster pump, roots vacuum pump, gas circulation cooling roots pump, oil diffusion pump, and molecular pump.It is applicable to vacuum coating, vacuum heat treatment, vacuum smelting, vacuum tube, bulb, refrigeration, chemicals, packing, forming, health and medical appliances, laboratory, vacuum drying machines and vacuum filtering.

Features:

 a. The pump can work continuously in the temperature between 5 to 40 centigrades and inlet pressure less than 1330Pa.

 b. Equipped with gas ballast valve to pump a little water vapor. It can last service life of  the  oil except the 2X-4A type.

c. Dedicated vacuum pump for making neon lights.

d. Many suction holes in the vacuum pump to save electricity.

Technical parameters:

Model

2X-4A

2X-8A

2X-15A

2X-30A

2X-70A

Pumping speed(L/s)

4

8

15

30

70

Ultimate Pressure

(Pa)

Partial pressure

6*10-2



Total pressure

1

Rotary speed(r/min)

450

320

320

450

420

Temperature()

40

Inlet diameter(mm)



25

40

40

65

80

Noise level(dBA)

75

78

80

82

86

Oil capacity(L)

1

1.5

2

3

4.2

Dimensions(mm)

540*335*380

790*430*540

790*530*540

780*500*560

910*650*700

Electro-vacuum differential pressure valve

DYC-Q25

DYC-Q40

DYC-Q40

DYC-Q65

DYC-Q80

Cooling speed(L/min)

-

-

-

71

72

G.W/N.W(Kg)

55/50

158/148

202/190

230/206

338/320

Notes:

Use seater mercury vacuum gauge to test in the inlet port of pump

b. Use thermocouple gauge, resistance gauge or some other total pressure type gauge to test

c. The diameter of inlet port and outlet port is G3/8〞
