Diaphragm Vacuum Pump
NANBEI Is Professional On Providing One-step Solution Of Laboratory Instruments And Equipment
GM-0.50B Diaphragm Vacuum Pump
“Nanbei” GM-0.50B diaphragm vacuum pump has features of more advanced design, higher efficiency, longer operating life. It is an all new product engaging in the new and high technology. It is mainly used in medicinal products analysis, tenuously chemical engineering, biochemical pharmacy, food examination, investigating and solving criminal case, etc. It is an ideal product used with the high-accuracy chromatogram apparatus, rotary evaporators, and it is the essential equipment in the laboratory.
The body of “Nanbei” GM-0.50II diaphragm vacuum pump is made of aluminum alloy through die casting. It is antiseptic, sprayed, agile and beautiful. It has the features of higher antisepsis, wider working range. It can meet requirements of all kinds of working environments.
Technique parameter
Speed of Evacuation (L/Min) | 30 | Pump Head | 2 |
Ultimate Pressure Vacuum | ≥0.095Mpa 50mbar | Voltage Rating | 230Vac, 50Hz |
Dimensions (L x B x H)（ｍｍ） | 300×120×235 | Temp of the body（℃） | <55 |
Motor Power（w） | 160 | Weight （Kg） | 10 |
Inlet (mm) Outlet (mm) | φ6 Silencer | Diaphragm Valves | NBR NBR |
Working Temp（℃） | 7—40 | Noise Level（dB） | <50 |
