High Speed Refrigerated Centrifuge
NANBEI Is Professional On Providing One-step Solution Of Laboratory Instruments And Equipment
Brand:NANBEI
Model:NB26M
Application:
NB26M High Speed Refrigerated Laboratory Centrifuge
Features:
AV motor of variable frequency and high toque,free from contamination caused by carbon dust,which helps to prolong the service life.
Imported variable frequency drive system and automatic control system to ensure steady and reliable operation.
France-based Tecumseh's compressor unit is used for the refrigeration system which allows free temperature adjustments and achieves high-precision temperature controls and reduced noise.
Maximum capacity 4x1000ml.
Multiple protections such as overheat,hypervelocity,electronic locking,and imbalance.
Metallic structure with a stainless steel cavity,hence strong and durable.
Intelligent interface featured by a TFT true-color LCD widescreen touch monitor,micro-computure control and simultaneous indication of both the set parameters and operation ones.
With 16 operation programs to be set by the user and the control parameters of the rotor to be modified at any time.
Operations can be programmed,10 levels of speed-up and speed-down time limits for the user to choose freely.
Can indicate the ascending and declining curves of the rotor,the centrifugal integral curves and the temperature curves.
Parameters
Model | NB26M |
Max Capacity | 4×1000ml |
Max Speed（r/min） | 25000 r/min |
Max RCF（×g） | 64983×g |
Standard rotor | 24×1.5/2.0ml |
Speed precision | ±30r/min |
Temp.control range | Frequency motor，micro control，direct driver |
Refrigeration system | Import fluoride-free compressor and control valve（R404a） |
Operation programe | 16 |
Temp.control range | -20℃～+40℃ |
Temp.precision | ±1℃ |
Timer range | 0-99h59min |
Power | AC220V 50Hz |
Noise | ＜68dB（A） |
Dimension （L×W×H） | 840×730×960mm |
Model | capacity | speed（r/min） | RCF(×g) |
Angle rotor | 24×1.5/2.0ml | 25000 | 64983 |
18×10ml | 23000 | 60460 | |
8×50ml | 21000 | 52356 | |
4×250ml | 15000 | 33800 | |
6×250ml | 14000 | 30070 | |
6×500ml | 10000 | 17700 | |
4×1000ml | 8000 | 12040 |
