1. Applications and features:
LDW Series Electronic tensile testing machine applies singlechip to measure and control parameters. Use mechanical loading and synchronous belt transmission, electron measurement, digital display, and the test speed can continuously change. The machine could display test force and displacement at the same time and has the function of holding the peak test force and displacement data. This machine is widely applying in mechanical property test such as rubber, plastic, wire and cable, textiles, waterproof materials, non-woven fabrics and other non-metallic materials and metal wire, metal foil, sheet metal and metal bar. The machine can do components and parts mechanical test, add accessories also can do compressed and bending test.
2. Main technical parameters:
Model | LDW Electronic Tensile Testing machine (single column) |
Max. testing force | 0.1kN--5 kN | 0.1kN--20 kN | 5kN、10kN、20kN、50kN | 100kN | 200kN | 300kN |
Test force range (kN) | 2%~100% |
Measurement accuracy | ±1% |
Valid test width | -- | 340mm | 380mm | 400mm | 550mm | |
Effective tensile space | 650mm | 650mm | 650mm | 600mm |
Speed range (mm/min) | 0.1~500 | 0.1~300 | 0.1~200 | 0.1~100 | 0.2~300 |
Speed Accuracy | ±1% |
Displacement measurement | Resolution ratio 0.1mm |
External dimensions | 400×300×1200mm | 620×370×1250mm | 700×410×1680mm | 760×480×1780mm | 1000×570×2200mm |
Power | 0.5kw | 0.8kw | 1.2kw | 1.5kw | 2kw | 3kw |
Voltage | 220V (Can configured with national standard voltage) |
Weight | 80kg | 120kg | 300kg | 500kg | 1200kg | 1300kg |
3. Functions
(1) Test result display: LCD digital display. Trial speed, displacement and peak value simultaneous display.
(2) Operating mode: button operation.
(3) Safety protection: Equipped with oil cylinder protection system, overload autostop system, overcurrent outostop system and emergency switch protect function.
