100kN 300kN 600kN 1000kN 2000kN 3000kN Microcomputer Controlled Electro-hydraulic Servo Universal Testing Machine

Brand:NANBEI

Model:WAW-100 WAW－300 WAW－600 WAW－1000 WAW－2000 WAW－3000

Application:

CONTACT NOW Chat Now

product details

1. Applications and features:

WAW Microcomputer Controlled Electro-hydraulic Servo Universal Testing Machine adopts the cylinder underneath type main engine,use a load cell to measure force. The machine configured Italian oil pump unit generator system, oil source and independent low noise clamping oil source. Use Digital program-controlled amplifier to achieve all sorts of model of the closed-loop control such as constant force, constant stress, constant deformation, constant speed, etc. In addition, this machine could accomplish metal and nonmetal materials tensile, compression, bending and shear tests. The machine can get parameter automatically, such as tensile strength, yield strength and elastic modulus E according to GB/T228 "metallic materials tensile test at room temperature method”.

2. Main technical parameters:

Model		WAW-100	WAW－300		WAW－600		WAW－1000	WAW－2000	WAW－3000
Maximum test force		100kN	300kN		600kN		1000kN	2000kN	3000kN
Host structure		Two column	Two column		Four column		Four column	Four column	Four column
Indication accuracy		±1% or ±0.5%
Load resolution (KN)		1/300000
Effective measurement range (KN)		2%～100%
Deformation accuracy		Better than ±0.5%
Deformation Resolution (μm)		2
Displacement indication Accuracy		Better than ±1%
Stress control speed (Mpa / s)		1～45
Strain control speed (mm / s)		0.001～0.5
Displacement control speed (mm / s)		0.02～3
Testing space	Stretching space (mm)	600		600		600	650	750	800
	Compression space (mm)	550		550		550	580	650	700
	effective width(mm)	460		460		500	520	650	750
	Cylinder（mm）	200		200		250	250	250	250
Host Size（mm）	hydro-cylinder underneath type (Double space)	720×580 ×1770		720×580 ×1770		800×620 ×2050	860×660 ×2170	950×620 ×3000	1100×750 ×3100
	hydro-cylinder placed up type（Single space）	850×540 ×2600		850×540 ×2600		980×640 ×3100	1100×720 ×3700	1300×900 ×4300	1300×900 ×4300
Round sample size（mm）		Φ5～Φ20		Φ10～Φ32		Φ13～Φ40	Φ20～Φ60	Φ20～Φ80	Φ20～Φ100
Flat sample size (thickness × width mm)		0～15×75		0～15×75		0～30×80	0～40×110	10～60×120	10～80×120
Total power（kw）		2.1		2.1		2.3	2.3	3.5	5
Voltage		220V and 380V ( Can configured with national standard voltage)
Weight（kg）		1500		1500		2500	3100	5000	6500

3. Functions

(1) Automatic computer servo control function

●Automatic control, measure, data collection and processing, draw and print the test curve and report

● Observe and control system can automatic calibration and zero set.

● Stepless speed regulating, in the study it can be arbitrary smooth transition and maintain the same speed.

● Data storage and curve amplifier. In the study can be arbitrary show different test curve.

● During the automatic operation process, it can change to artificial control.

● Have automatic protection function, the protection range can be set in a random manner.

(2) Microcomputer system: Use the Lenovo brand microcomputer as host machine to finish the testing setting setup, data acquisition, display and print test results etc(include: main engine, 17 "LCD and large capacity hard disk); equipped with KQL-PowerTest2001 in English and Chinese version which is intelligent test software packages; Can provide standard measurement and judgment of performance parameter for all kinds of material, add up and processing the data; output various requirements of the test report and test format curve.

(3) Computed mode: Hand valve operation, and equipped with manual control operation box, contains 6 buttons (rise，fall, upper clamping, bottom clamping, upper loosen, bottom loosen), the operation more convenient, safe and reliable.

(4) Safety protection: Equipped with oil cylinder protection system, overload autostop system, overcurrent outostop system and emergency switch protect function.

4．Advantages:

(1) Use manual and automatic operation to raise the working efficiency.

(2) Adopt spoke structure loading sensor. It has the advantage of high precision and stable performance.

(3) Equipped with Italian oil cylinder protection system, low noise and stable oil.

(4) Hydraulic sealed with double sealing structure, effectively prevent the leakage of oil and oil leakage.

(5) Configured Clamp mouth protection board, this could effectively prevent the splint of clamp mouth scratched.

(6) Equipped with Universal Ball Head Institution, this could be automatically adjustable cores, and to ensure the sample clipped absolutely right.

5. Disadvantages:

The cost of the machine is higher than WES and WEW. The cleanness requirement of the hydraulic oil is much higher.
