HR-150B Rockwell Hardness Tester
HR-150B Rockwell Hardness Tester

HR-150B Rockwell Hardness Tester

Brand:NANBEI

Model:HR-150B

Application:

product details

Product Details:

MODEL HR-150B ROCKWELL HARDNESS TESTER



Feature & Use:

* High travel of test anvil in vertical direction and it is suitable for testing of large test piece

* Manual testing process, no need for electric controlling

* It's steady and reliable for testing of curved surface

* Precision conforms to the Standards of GB/T 230.2, ISO 6508-2 and ASTM E18

It's suitable to determine the Rockwell hardness of ferrous, non-ferrous metals and non-metal materials. It can be widely applied in the Rockwell hardness testing for heat treatment materials, such as quenching, hardening and tempering, etc.



Specifications

Measuring range: 20-88HRA, 20-100HRB, 20-70HRC

Test force: 588.4, 980.7, 1471N (60, 100, 150kgf)

Max. height of test piece: 400mm

Depth of throat: 160mm

Min. scale value: 0.5HR

Dimensions: 548 x 326 x 1025mm

Weight: approx. 140kg



Standard accessories

Large flat anvil: 1 pc.

Small flat anvil: 1 pc.

V-notch anvil: 1 pc.

Diamond cone penetrator: 1 pc.

1/16" steel ball penetrator: 1 pc.

Rockwell standardized block: 5 pcs.
