Rotary Oscillator
NANBEI Is Professional On Providing One-step Solution Of Laboratory Instruments And Equipment
NB ROTARY AGITATOR
Rotary Agitator conforms to the extraction procedure toxicity of solid waste, is the environment protect industry standard of the people’s republic of China and also the appointed equipment for Measurement of sulfuric-nitric (HJ2099-2007) and ethanoic acid buffer solution (HJ300-2007).
Rotary Agitator :Toxicity Characteristic Leaching Procedure(TCLP)
Standard of China 5085.3-2007（HJ/T299-2007）
Standard of China GB16889-2008（HJ/T300-2007）
EPA Method 1311
The device can be used for:
environment monitor, relevant industry of toxicity distinguishesl research, management and handling like solid waste management;
For universities, chemical engineering, agriculture, sanitation, forestry, QC, food and medicine analysis and customs producing test and scientific research.
ＨＤ Rotary Agitator
Technical parameter model number | NB-06 | NB-08 | NB-10 | NB-12 |
sample bottle number | 6个 | 8个 | 10个 | 12个 |
Sample bottle capacity | 2L | |||
voltage rating（V） | 220V,50HZ | |||
power of motor（W） | 90W | 120W | 140W | 160W |
Rotating mode | forward / backward | |||
speed（r/min） | 0～60r/min | |||
Temperature control: room temperature（℃） | Room temperature～65℃ | |||
temperature control accuracy（℃） | ±1℃ | |||
Time control（2）（h） | 0～24 h Rotating time customers’ requirements | |||
size(mm) (length width height ) | 800*550*700 | 980*550*700 | 1160*550*700 | 1400*550*700 |
Weight kg | 50 | 53 | 56 | 60 |
Material | total stainless steel on outside | |||
Notice | Mode can be designed according to customers’ requirements | |||
Main Characteristic:
1,first domestic independently R&D and produce, utilize the advanced technology and user-friendly design philosophy from Germany.
2,Outside material is total stainless steel with elegant appearance and easy to clean.
3,Protection cover is designed with a push and pull pattern to ensure it works under totally enclose environment.
4,Organic glass view window to see through and know the running status all too easy.
5,Stable security device with unbalanced load protection, leakage protection and flip-open cover.
6,Temperature real-time control with slim fluctuation.
7,folder-disk button fixed to ensure sample bottle stable.
8,Digital electronic speed tuner, automated mode setting, better vibration effects.
9,Multiple rotation modes, forward, backward, forward and backward, high speed, low speed.
10,Long running time with little noise, easy to maintain and long useful time.
11,Good compatibility, can be put on a 2L glass bottle, PE bottle and ZHE.
