Lab Hotplate NB-550-S

Brand:NANBEI

Model:NB-550-S

Application:

CONTACT NOW Chat Now

product details

Key Features

• LED screen shows temperature

• Max. temperature up to 550°C

• Separate safety circuits with fixed safety temperature of 580°C

• External temperature control is possible by connecting the temperature sensor(PT 1000) with an accuracy at ±0.5°C

• Glass ceramic work plate provides excellent chemical-resistant performance and most efficient heat transfer

• The “HOT” warning will flash if the work plate temperature is above 50°C even when the hotplate is turned off

Specification

Specifications	NB550-S
Work plate Dimension	184x184mm(7 inch)
Work plate material	Glass ceramic
Power	1010W
Heating Power	1000W
Voltage	100-120/200-240V,50/60Hz
Heating position	1
Heating temperature range	Room temp.-550°C,increment 5°C
Control accuracy of work plate	±10°C
Safety temperature	580°C
Temperature display	LED
Temperature display accuracy	±1°C
External temperature sensor	PT1000(±0.5°C)
Heating warning	50°C
Protection class	IP21
Dimension [W x D x H]	215x360x112mm
Weight	4.5kg
Permissible ambient temperature and humidity	5-40°C, 80%RH

Order Info

P/N	Descriptions	Power supply
HP550-S	LED Digital 7’’ Square Hotplate，glass ceramic hotplate，heating temperature up to 550°C,with PT1000 for free (18900016),need to buy support clamp 18900017	USA plug,100V-120V/50Hz/60Hz
		Cn plug,200V-240V/50Hz/60Hz
		Euro plug,200V-240V/50Hz/60Hz
		UK plug,200V-240V/50Hz/60Hz
