Magnetic Stirrer
NANBEI Is Professional On Providing One-step Solution Of Laboratory Instruments And Equipment
MS7-Pro series:
Features:
1. Speed range of 100-1500 rpm
2. Max. Stirring quantity 20L
3. Glass ceramic plate is extremely resistant to corrosion and easily clean
4. LCD displays target and actual speeds.
5. Brushless DC motor maintenance free and explosion-proofed accurately control speed
Parameters:
| MS7-Pro |
Dimension of work plate [mm] | 184x184 (7 inch) |
Work plate material | Glass ceramic |
Motor type | DC brushless motor |
Motor rating input [W] | 18 |
Motor rating output [W] | 10 |
Power [W] | 50 |
Voltage [VAC] | 100-120/200-240 |
Frequency [Hz] | 50/60 |
Stirring positions | 1 |
Max. stirring quantity[H2O], L | 20 |
Max. magnetic bar(L x Ø) [mm] | 80 |
Speed range [rpm] | 100-1500 |
Speed display | LCD |
Speed display resolution [rpm] | ±1 |
Protection class according to DIN EN60529 | IP21 |
Dimension [W x D x H] mm | 215x360x112 |
Weight [kg] | 5.3 |
Permissible ambient temperature [°C] | 5-40 |
Permissible relative humidity | 80% |
