HBV-30A Brinell Vickers Hardness Tester

MODEL HBV-30A BRINELL & VICKERS HARDNESS TESTER

Feature & Use:

* Automatic testing process, no human operating error

* Precision conforms to GB/T 4340.2, GB/T 231.2, ISO6506-2, ISO6507-2, ASTM E92 and ASTM E10

* It's suitable to determine the Vickers hardness of steel, non-ferrous metals, ceramics, treated layers of metal surface, and the hardness grads of carburized, nitrided and hardened layers of metals. It is also suitable to determine the Vickers hardness of micro and super thin parts and the Brinell hardness of soft metals and small parts.

Specifications

Measuring range: 8-650HBW, 10-3000HV

Test force: 9.807, 24.52, 49.03, 98.07, 196.1, 294.2N

                    (1, 2.5, 5, 10, 20, 30kgf)

Max. height of test piece: 130mm

Depth of throat: 100mm

Magnifications of the measuring system: 500X, 125X

Min. scale value of the optical micrometer: 0.25um

Power supply: 220 AC or 110V AC, 50 or 60Hz

Dimensions: 438 x 382 x 708mm

Weight: approx. 88kg

Standard accessories

Coordinate anvil: 1 pc.

Large flat anvil: 1 pc.

Small flat anvil: 1 pc.

V-notch anvil: 1 pc.

Tungsten carbide ball penetrator: Φ1, Φ2mm, 1 pc. each

Diamond pyramid penetrator: 1 pc.

Brinell standardized block: 2 pcs.

Vickers standardized block: 2 pcs.

Electronic calculator: 1 pc.
