Hydralic Lifting Explosion Proof Paint Disperser Machine with Frequency Speed Control
Application:
High speed disperser is mainly used for Paint,Coating,Printing-ink,Resin,Food,Pigment, Glue, Adhesive, Dye, Cosmetic, etc.
Description:
hydraulic lifting
2.Material:stainless steel
3.Whole cooper wire Explosion-proof motors
4.Frequency speed adjustable
5.The voltage and plug can be changed to same as your local voltage, this is for free.
Voltage:110V/60HZ 220V/60HZ 220V/50HZ 380V/50HZ
Plug:EU,UK,America,Italy,Switzerland,South Africa.
It’s better you can tell us your local voltage and send plug pictures.
6.If you can not decision to choose suitable model, please feel free contact Angelina.
She will reference suitable model to you according to your material and capacity.
Technical data:
| Type | NFS-2.2 | NFS-4 | NFS-5.5 | NFS-7.5 | NFS-11 | NFS-15 | NFS-18.5 | NFS-22 | |
| Main Motor Power (Kw) | 2.2 | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | |
| Impeller Rotational Speed (rpm) | 80~1250 or customized | ||||||||
| Dispersion Plate Diameter(mm) | 150~200 | 150~200 | 200~250 | 250~300 | 300 | 350 | 350 | 350~400 | |
| Stirring-axis Max Stroke (mm) | 1000 or customized | ||||||||
| Installation Height (mm) | 3100 | 3100 | 3100 | 3100 | 3100 | 3200 | 3200 | 3200 | |
| Overall Dimensions(mm) | L | 1500 | 1500 | 1500 | 1500 | 1500 | 2000 | 2000 | 2000 |
| W | 550 | 550 | 550 | 550 | 550 | 700 | 700 | 700 | |
| H | 2100 | 2100 | 2100 | 2100 | 2100 | 2200 | 2200 | 2200 | |
| Weight (Kg) | 600 | 640 | 710 | 730 | 830 | 930 | 1050 | 1070 | |
