DDS-11C Lab Conductivity Meter
Introduction
| ●With built-in microprocessor chip, it has automatic calibration, automatic temperature compensation, data storage, and feature setting etc. |
| ●Adopt advanced and original conductivity measurement technology, use 1 pc of conductivity electrode (K=1), it can meet measuring accuracy requirement for range within 0.5μS/cm ~ 200mS/cm by using only one-point calibration. |
| ●Automatically recognize 8 kinds of conductivity standard solution. User can choose anyone from two series of solutions: Europe & USA series and China series |
| ●Equips Conductivity/ATC plastic electrode. Its measurement result is fast and precise. |
Specifications
| Category | Product Name | Basic features and specifications |
| Conductivity | Measuring Range | Conductivity:（0 ~199.9）μS/cm （200~1999）μS/cm （2.00~19.99）mS/cm （20.0~199.9）mS/cm |
| Resolution | 0.1/1μS/cm 0.01/0.1 mS/cm | |
| Accuracy | Meter：±1.0% FS, with electrode: ±1.5% FS | |
| Temp. Compensation range | （0 ~ 50）℃ (automatic or manual) | |
| Electrode Constant | 0.1 / 1 / 10 cm-1 | |
| Other Technical Specifications | Data Storage | 50groups |
| Storage Content | Measuring value serial number, measuring value, and temperature | |
| Power | DC9V | |
| Size and Weight | (160×190×70)mm/750g(Meter) | |
| Quality and Safety Certification | ISO9001:2008, CE and CMC | |
| Working Condition | Environment Temperature | 5 ~ 35 ℃（0.01） |
| Environmental Humidity | ≤85% | |
Standard Kit Includes
| 1. DDS-11C conductivity meter | 1 unit |
| 2. 2301-F plastic conductivity electrode(K=1,ATC) | 1 pc |
| 3. 1413μS/cm conductivity standard solution (50mL) | 1bottle |
| 4. 9V power adapter | 1 pc |
| 5. 600 electrode holder | 1 pc |
| 6. Operation manual | 1 pc |
